Semiconductor Logistics
Doesn't Forgive Shortcuts.
Precision Is Built into
Everything We Do.
From JEDEC-compliant ESD environments and Korea-to-Taiwan semiconductor corridors to N2 dry cabinet storage and in-house IC programming, Omni helps manufacturers protect yield, maintain product integrity and keep supply chains moving.
The Difference Is
in the Protocols
Semiconductor products require controls that extend beyond traditional freight operations. Cleanroom disciplines, ESD protection, environmental monitoring, traceability, and specialized processing capabilities are often as critical as transportation itself. Our facilities function as an extension of your supply chain, combining the engineering depth of an OSAT partner with the global reach of a logistics network. From wafers and packaged ICs to HBM memory and advanced semiconductor components, we help protect product integrity, maintain traceability, and keep critical supply chains moving.
JEDEC-Compliant ESD Warehousing
Certified Class 10,000 (ISO 7) cleanrooms, with JEDEC-standard ESD zones featuring continuous grounding monitoring and anti-static handling for raw wafers, bare die, and packaged ICs.
In-House Value-Added Services (VAS)
Reduce handoffs and maintain chain-of-custody through integrated in-house services. We execute IC programming, system-level and board testing, marking, tape-and-reel, dry baking, and vacuum packing, all in-house.
Reverse Logistics & RMA
Safeguard post-sale product integrity. Our engineering teams manage 100% incoming inspection, serialized sorting, functional board repair, and component restaging, turning potential losses into recovered assets, helping customers recover product value while maintaining traceability and quality control.
A component that passed visual inspection and failed functional testing. A wafer exposed to the wrong humidity for six hours in transit. These aren't edge cases. They're what happens when the logistics environment wasn't built for this freight. Ours was.
Your Yield Doesn't Have Room for the Wrong Partner.
| Capability | Traditional Freight Model | ✓ Omni Semiconductor Operating Model |
|---|---|---|
| Handling & Environment | ||
| ESD-safe environmentsJEDEC-compliant | ✗ Limited support | ✓ JEDEC-compliant ESD rooms with anti-static packaging |
| Climate-controlled warehousingTemp & RH documented | ~ Extra cost; inconsistent | ✓ Documented temp & RH parameters for every leg |
| N2 dry cabinet storageWafer & die bank protection | ✗Inconsistent availability" | ✓ N2 dry cabinet for wafer storage supporting multiple subcons |
| In-House Value-Added Services | ||
| IC programmingOn-demand ROM | ✗Typically outsourced | ✓ On-demand programming to minimize finished-goods inventory |
| System-level testingHigh-capacity automated testing | ✗Not core capability | ✓ High-capacity testing with 400+ test positions |
| Tape & reel conversion2D/3D vision equipped | ✗ Limited support | ✓ Tray/tube to tape and vice versa |
| Dry baking (recovery)Remove moisture | ✗ Scrapping only | ✓ Industrial ovens with CDA and nitrogen — recovery instead of scrap |
| Visibility & Compliance | ||
| Real-time visibilityEnvironmental data logging | ~ Basic tracking only | ✓ Full visibility with exception-triggered alerts and data logging |
| ERP / SAP integrationLive system connectivity | ✗ Manual updates | ✓ Live API integration with your ERP, SAP, or WMS |
| Customs brokerageDual-use export controls | ~ Third-party only | ✓ Licensed in-house brokers with dual-use export expertise |
Engineering-First
Supply Chain
Moving wafers, advanced packaging, and HBM memory requires more than transportation.It requires teams that understand semiconductor handling requirements before product enters the supply chain.
3200 Olympus Blvd.
Dallas, TX 75019
What happens after you submit:
A member of our semiconductor logistics team will reach out within one business day. No pitch deck, no pressure. Just a direct conversation about your semiconductor supply chain, handling requirements, and where operational risk exists today.
Taiwan Capabilities
Network Coverage
Coast-to-Coast Reach.
Precision at Every Point.
Yield protection doesn't start at the fab. It starts the moment semiconductor freight enters the supply chain and that moment happens in Taiwan. Wafers, packaged ICs, and HBM memory all move through Taiwan's manufacturing and integration ecosystem before reaching customers worldwide.
The handling decisions made at that origin point are what determine whether product arrives protecting yield or compromising it. Omni's Taiwan operation has been purpose-built for exactly this since 2006.
Five warehouses, 1 million square feet, FTZ capabilities, and 300+ specialists trained in semiconductor handling protocols. Having Omni in Taiwan isn't a logistics convenience. It's a yield protection decision.
